Technical Specification | |
---|---|
Compatibility: | MELLANOX |
Connector Type: | MPO/MTP |
DOM: | Yes |
Form Factor: | QSF28 |
Media Type: | MMF |
Maximum Link Length: | 100 Meters |
Speed: | 100G |
Transceiver Type: | 100GBASE-SR4 |
Wavelength: | 850nm |
Optical Specification | |
---|---|
Optical Power | -8.4dBm to 2.4dBm (Per Lane) |
RX Sensitivity | -10.3dBm (Per Lane) |
Physical Specification | |
---|---|
Shipping Dimension | 1.2 in. x 2.75 in. x 4.75 in. |
Shipping Weight | 0.4 |
Miscellaneous | |
---|---|
Country Of Origin | USA |
HTS-Harmonized Code (US) | 8517.70.0000 |
ECCN | 5A991 |
Compliance: | TAA, RoHS, MSA, IEEE 802.3z |
