Delivering long-range 1.25Gbps performance over single-mode fiber, this 100% OEM compatible 1000BASE-LX SFP transceiver supports up to 10KM at 1310nm. It features DOM for real-time diagnostics, low power draw, and full TAA, RoHS, and IEEE compliance. Ready to ship today from our California warehouse.
✓ Coded In-House – Guarantees Latest Code Revision
✓ Tested In-House – Guarantees 100% System Compatibility
✓ Warrantied – Guarantees 100% Lifetime Replacement Warranty
| Technical Specification | |
|---|---|
| Compatibility | Brocade |
| Connector Type | Duplex LC |
| DOM | Yes |
| Form Factor | SFP |
| Media Type | SMF |
| Maximum Link Length | 10KM |
| Speed | 1.25G |
| Transceiver Type | 1000BASE-LX |
| Wavelength | 1310nm |
| Optical Specification | |
| Optical Power | -9.5dBm to -3dBm |
| RX Sensitivity | -22dBm |
| Physical Specification | |
| Shipping Dimension | 1.2 in. x 2.75 in. x 4.75 in. |
| Shipping Weight | 0.4 lb |
| Miscellaneous | |
| Country Of Origin | USA |
| HTS-Harmonized Code (US) | 8517.70.0000 |
| ECCN | 5A991 |
| Compliance | TAA, RoHS, MSA, IEEE 802.3z |
E1MG-LX-OO
Sale price$17.00
Choose options
E1MG-LX-OO
Sale price$17.00
